Sigma-Aldrich 735167 Fluorine doped tin oxide coated glass slide L × W × thickness 300 mm × 300 mm × 2.2 mm, surface resistivity ~7 Ω/sq 1 Adet
Kategori
Marka
Stok Kodu
LB.SA.735167-1EA
Kısa Bilgi
Synonym(s): FTO glass EC Number: 242-159-0 NACRES: NA.23
| Sigma-Aldrich 735167 Fluorine doped tin oxide coated glass slide |
| Synonym(s): FTO glass EC Number: 242-159-0 NACRES: NA.23 |
|
PROPERTIES
description Haze: 5%
Quality Level 100 composition SnO2/F surface resistivity ~7 Ω/sq L × W × thickness 300 mm × 300 mm × 2.2 mm transmittance 80-82% (visible) DESCRIPTION General description The coating thickness of Fluorine doped tin oxide on glass slide is ∼ 550 nm. The glass has a refractive index of ∼ 1.52 and the SnO2:F coating is ∼ 1.85. Application Fluorine doped tin oxide coated glass slide (FTO glass) can be used as a substrate for the fabrication of dye sensitized solar cells (DSSCs) and photovoltaic cells (PVs).[1][2] |
