Sigma-Aldrich 735825 Silver conductive paste 25 gr
| Sigma-Aldrich 735825 Silver conductive paste 25 gr |
|
Synonym(s): Silver Paste DGP80 TESM8020
Linear Formula: Ag
CAS Number: 7440-22-4
Molecular Weight: 107.87
MDL number: MFCD00003397
PubChem Substance ID: 329765060
NACRES: NA.23 |
|
PROPERTIES
Quality Level 200
form paste (microparticles)
concentration ≥75%
resistivity 1-3 * 10^-5 Ω-cm (conductive paste) 1.59 μΩ-cm, 20 °C
matrix
α-Terpineol (Dispersion
Recommended washing solvent = polar solvent (Ethanol, IPA, Methanol, etc)
Recommended substrates = ITO film & glass, plastic film)
particle size 200 nm (80%) <5 nm (20%)
viscosity 100,000-300,000 cP, 0.4 rpm, Brookfield
bp 2212 °C (lit.)
mp 960 °C (lit.)
transition temp curing temperature 120-150 °C (30-60 min)
density 10.49 g/cm3 (lit.)
storage temp. 2-8 °C
SMILES string [Ag]
InChI 1S/Ag
InChI key BQCADISMDOOEFD-UHFFFAOYSA-N |
